Calculate the shaded area as given below:
Answer & explanation
Correct answer: option 1
The correct answer is Option (1) → \(\displaystyle\frac{8}{3}\) sq. units
The shaded region is bounded by the parabola \(y^2=2x\) and the two lines meeting at (−2, 0). It is symmetric about the x-axis, so the area is twice the area above the x-axis.
Above the x-axis, the region runs from y = 0 to y = 2. Writing both boundaries as x in terms of y:
\( \displaystyle y=\frac{x}{2}+1 \;\Rightarrow\; x=2y-2 \quad \text{(left boundary)} \)
\( \displaystyle y^2=2x \;\Rightarrow\; x=\frac{y^2}{2} \quad \text{(right boundary)} \)
Integrating along the y-axis (right boundary minus left boundary):
\( \displaystyle \text{Area above the x-axis}=\int_{0}^{2}\left(\frac{y^2}{2}-(2y-2)\right)dy \)
\( \displaystyle =\left[\frac{y^3}{6}-y^2+2y\right]_{0}^{2} \)
\( \displaystyle =\frac{8}{6}-4+4=\frac{4}{3} \)
So the shaded area is
\( \displaystyle 2\times\frac{4}{3}=\frac{8}{3}\ \text{sq. units} \)
