The standard reduction potential for \(Sn^{4+}/Sn^{2+}\) is \(+ 0.15 V\) and for \(Cr^{3+}/Cr\) is \(- 0.74 V\). These two half-cells, coupled in their standard states, are connected to make a cell. The galvanic cell can be correctly represented by: |
\(Sn^{2+}(aq) |Sn^{4+} (aq)||Cr(s)|Cr^{3+}(aq)\) \(Sn^{4+}(aq)|Sn^{2+}(aq) ||Cr^{3+} (aq)|Cr(s)\) \(Cr(s)|Cr^{3+}(aq)||Sn^{4+} (aq) | Sn^{2+}(aq)\) \(Cr(s)|Cr^{3+}(aq)||Sn^{4+}(aq) |Sn^{2+}(s)\) |
\(Cr(s)|Cr^{3+}(aq)||Sn^{4+} (aq) | Sn^{2+}(aq)\) |
The correct answer is option 3. \(Cr(s)|Cr^{3+}(aq)||Sn^{4+} (aq) | Sn^{2+}(aq)\). Let us break down the explanation: In a galvanic cell, oxidation occurs at the anode and reduction occurs at the cathode. The half-cell with the higher standard reduction potential (more positive) is considered the cathode, where reduction occurs, while the half-cell with the lower standard reduction potential (less positive) is considered the anode, where oxidation occurs. Given: Standard reduction potential for \(Sn^{4+}/Sn^{2+}\) is \(+0.15 \, \text{V}\). Standard reduction potential for \(Cr^{3+}/Cr\) is \(-0.74 \, \text{V}\). 1. We identify that \(Sn^{4+}/Sn^{2+}\) has the higher standard reduction potential (\(+0.15 \, \text{V}\)), making it the cathode half-reaction. 2. \(Cr^{3+}/Cr\) has the lower standard reduction potential (\(-0.74 \, \text{V}\)), indicating it undergoes oxidation and therefore should be the anode half-reaction. To represent the galvanic cell correctly: The cathode half-reaction (\(Sn^{4+}(aq) + 2e^- \rightarrow Sn^{2+}(aq)\)) is written on the left side. The anode half-reaction (\(Cr(s) \rightarrow Cr^{3+}(aq) + 3e^-\)) is written on the right side. So, the correct representation of the galvanic cell is: \[ Cr(s)|Cr^{3+}(aq)||Sn^{4+}(aq) | Sn^{2+}(aq) \] This arrangement ensures that electrons flow from the anode (Cr) to the cathode (Sn), as expected in a galvanic cell. |
