The graph of the inequality \(2x + y \gt 5\) is :
Answer & explanation
Correct answer: option 4
The correct answer is Option (4) → half plane that neither contains origin nor the points on and below the line \(2x + y = 5\)
The line 2x + y = 5 divides the plane into two half planes. The inequality holds on one side only.
Test the origin (0, 0):
\(2(0) + 0 = 0\), and \(0 \gt 5\) is false
So the origin is not in the graph, and neither is the side of the line containing it (the points below the line, where 2x + y < 5).
The inequality is strict (>, not ≥), so the points on the line, where 2x + y = 5, are also left out.
The graph is the half plane above the line, away from the origin, without the line itself.
