Calculate the emf of the Daniell cell when the concentration of [Cu2+…

Daniell Cell

Electrochemistry is the study of the production of electricity from energy released during spontaneous chemical reactions and the use of electrical energy to bring about non-spontaneous chemical transformations. The cell below represents Daniell cell which converts the chemical energy liberated during the redox reaction to electrical energy.

Zn(s) + Cu²⁺(aq) → Zn²⁺(aq) + Cu(s)

The reaction is a combination of two half-cell reactions, one called the oxidation half-cell and the other called the reduction half-cell. Each half-cell consists of a metallic electrode dipped into an electrolyte. The two half-cells are connected through a metallic wire and switch externally. The electrolyte of the two half cells is connected internally through a salt bridge. At each electrode-electrolyte interface there is a tendency for metal ions from the solution to deposit on the metal electrode, trying to make it positively charged. At the same time, metal atoms of the electrode have a tendency to go into the solution as ions and leave behind the electrons at the electrode, trying to make it negatively charged. A potential difference develops between the electrode and the electrolyte, which is called electrode potential. When the concentrations of all the species involved in a half-cell is unity, then the electrode potential is known as the standard electrode potential.

For a general half-cell; Mⁿ⁺(aq) + ne⁻ → M(s), the Nernst equation is written as

\( E_{(M^{n+}/M)}=E^{o}_{(M^{n+}/M)}-\frac{RT}{nF}\ln\frac{1}{[M^{n+}]} \)

where \( E^{o}_{(M^{n+}/M)} \) is the standard reduction potential of the half-cell, R is gas constant (8.314 J K⁻¹ mol⁻¹), F is Faraday constant (96487 C mol⁻¹), T is temperature in kelvin and [Mⁿ⁺] is the concentration of the species, Mⁿ⁺.
