A pair of adjacent coils has a mutual inductance of 2.0 H. If the current in one coil changes from 0 to 30 A in 0.5 s, the change of the magnetic flux linked with the other coil would be |
30 Wb 120 Wb 50 Wb 60 Wb |
60 Wb |
The correct answer is Option (4) → 60 Wb Mutual inductance relation: $M = \frac{\Delta \Phi}{\Delta I}$ So, $\Delta \Phi = M \Delta I$ Given: $M = 2.0 \ \text{H}$, $\Delta I = 30 - 0 = 30 \ \text{A}$ $\Delta \Phi = 2.0 \times 30 = 60 \ \text{Wb-turn}$ Change of flux linked = 60 Wb-turn |
